| Nomor Bagian | AM480272H3TMQW-TW1H |
| Merek | AMPIRE |
| Ukuran | 4.3 |
| Aplikasi | Industrial |
| Resolusi | 480×272 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 250:1 |
| Warna | 65K/262K |
| Lampu latar | WLED |
| Antarmuka | 8/9/16/18-bit |
| merek | AMPIRE |
| model | AM480272H3TMQW-TW1H |
| ukuran diagonal | 4.3 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 480(RGB)×272 [WQVGA] 128PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 95.04(H)×53.856(V) mm |
| garis besar redup. | 105.5(H)×67.2(V) ×7.91(D) mm |
| pencahayaan | 400 cd/m² (Typ.) |
| rasio kontras | 250:1 (Typ.) (TM) |
| arah pandangan | 6 o'clock |
| waktu merespon | 15/35 (Typ.)(Tr/Td) |
| sudut pandang | 70/70/35/55 (Typ.)(CR≥10) |
| Modus operasi | TN, Normally White, Transmissive |
| warna pendukung | 65K/262K 52% NTSC |
| sumber cahaya | WLED [7S1P] , 15K hours , W/O Driver |
| berat | TBD |
| dirancang untuk | Industrial |
| kecepatan bingkai | 60Hz |
| panel sentuh | 4-wire Resistive Touch |
| tipe antarmuka | 8/9/16/18-bit 6800/8080 parallel , 40 pins Connector |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
