| Nomor Bagian | AM1024600K7TMQW-T62H |
| Merek | AMPIRE |
| Ukuran | 7.0 |
| Aplikasi | Industrial |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 700:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antarmuka | |
| merek panel | AMPIRE |
| ukuran panel | 7.0" |
| resolusi | 1024(RGB)×600, WSVGA, 169PPI |
| area tampilan | 153.6(W)×90(H) mm |
| kecerahan | - |
| sudut pandang | 75/75/70/75 (Typ.)(CR≥10) |
| tampilan terbaik di | - |
| menampilkan warna | 262K/16.7M |
| frekuensi | 60Hz |
| berat | - |
| model panel | AM1024600K7TMQW-T62H |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| rasio kontras | 700:1 (Typ.) (TM) |
| mode tampilan | TN, Normally White, Transmissive |
| waktu merespon | 20/20 (Typ.)(Tr/Td) |
| jenis lampu | WLED |
| layar sentuh | PCAP |
| aplikasi | Industrial |
