| Nomor Bagian | AM-800600K2TMQW-04H |
| Merek | AMPIRE |
| Ukuran | 10.4 |
| Aplikasi | Industrial |
| Resolusi | 800×600 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | AMPIRE |
| ukuran panel | 10.4" |
| resolusi | 800(RGB)×600, SVGA, 96PPI |
| area tampilan | 211.2(W)×158.4(H) mm |
| ukuran garis besar | 243(W)×185.6(H) mm |
| kecerahan | 500 cd/m² (Typ.) |
| sudut pandang | 70/70/50/60 (Typ.)(CR≥10) |
| tampilan terbaik di | 6 o'clock |
| menampilkan warna | 262K 50% NTSC |
| frekuensi | 60Hz |
| berat panel | - |
| antarmuka sinyal | LVDS (1 ch, 6-bit) , 20 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -35 ~ 85 °C |
| model panel | AM-800600K2TMQW-04H |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | 214.8(W)×162.7(H) mm |
| permukaan | - |
| rasio kontras | 500:1 (Typ.) (TM) |
| mode tampilan | TN, Normally White, Transmissive |
| waktu merespon | 5/15 (Typ.)(Tr/Td) |
| jenis lampu | WLED , 30K hours , With LED Driver |
| layar sentuh | Without |
| aplikasi | Industrial |
