| Nomor Bagian | AM-800480N3TZQW-57H |
| Merek | AMPIRE |
| Ukuran | 5.0 |
| Aplikasi | Industrial Automotiv |
| Resolusi | 800×480 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 262K |
| Lampu latar | 3S6P |
| Antarmuka | |
| pabrikan | AMPIRE |
| nama model | AM-800480N3TZQW-57H |
| ukuran layar | 5.0 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 800(RGB)×480 (WVGA) 188PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 108 × 64.8 (H×V) |
| garis besar (mm) | 119.7 × 78.3 × 10.05 (H×V×D) |
| area bezel (mm) | 109.6 × 66.4 (H×V) |
| perlakuan | - |
| pencahayaan | 1000 cd/m² (Typ.) |
| rasio kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| tanggapan | 30 (Typ.)(Tr+Td) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | IPS, Normally Black, Transmissive |
| kedalaman warna | 262K |
| lampu latar | 3S6P WLED , 50K hours , With LED Driver |
| massa | - |
| digunakan untuk | Industrial Automotive Display |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
