| Nomor Bagian | AM-800480D1TMQW-00H |
| Merek | AMPIRE |
| Ukuran | 8.0 |
| Aplikasi | Industrial Automotiv |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antarmuka | |
| merek | AMPIRE |
| model | AM-800480D1TMQW-00H |
| ukuran diagonal | 8.0 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 800(RGB)×480 [WVGA] 116PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 176.64(H)×99.36(V) mm |
| garis besar redup. | 192.8(H)×116.9(V) ×6.7(D) mm |
| daerah bezel | 180.1(H)×103.4(V) mm |
| perlakuan | Antiglare |
| pencahayaan | 450 cd/m² (Typ.) |
| rasio kontras | 500:1 (Typ.) (TM) |
| arah pandangan | - |
| waktu merespon | 10/15 (Typ.)(Tr/Td) |
| sudut pandang | 70/70/50/70 (Typ.)(CR≥10) |
| Modus operasi | TN, Normally White, Transmissive |
| warna pendukung | 262K/16.7M |
| sumber cahaya | WLED , 20K hours , W/O Driver |
| berat | 251g (Typ.) |
| dirancang untuk | Industrial Automotive Display |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
