| Nomor Bagian | AM-800480BCTMQW-T00H |
| Merek | AMPIRE |
| Ukuran | 5.0 |
| Aplikasi | Industrial |
| Resolusi | 800×480 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 600:1 |
| Warna | 16.7M |
| Lampu latar | 6S2P |
| Antarmuka | Parallel |
| pabrikan | AMPIRE |
| ukuran layar | 5.0 inch |
| nomor piksel | 800(RGB)×480 (WVGA) 188PPI |
| area aktif (mm) | 108 × 64.8 (H×V) |
| pencahayaan | 340 cd/m² (Typ.) |
| sudut pandang | 75/75/60/70 (Typ.)(CR≥10) |
| pemandangan bagus di | 6 o'clock |
| kedalaman warna | 16.7M 52% NTSC |
| massa | - |
| tingkat penyegaran | 60Hz |
| jenis sinyal | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| nama model | AM-800480BCTMQW-T00H |
| tipe layar | LCM , a-Si TFT-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | 129.9 × 86.7 × 7.18 (H×V×D) |
| rasio kontras | 600 : 1 (Typ.) (TM) |
| tanggapan | 4/12 (Typ.)(Tr/Td) ms |
| mode kerja | TN, Normally White, Transmissive |
| lampu latar | 6S2P WLED , 50K hours , No Driver |
| digunakan untuk | Industrial |
| layar sentuh | PCAP |
| C050FTN01.0 | AUO | 5.0 | 480×234 |
| EJ050NA-01G | Innolux | 5.0 | 800×480 |
| G050VTN01.1 | AUO | 5.0 | 800×480 |
| H495TAN01.1 | AUO | 5.0 | 720×1280 |
| HSD050FMW2-D00 | HannStar | 5.0 | 540×960 |
| HSD050I9W1-A00 | HannStar | 5.0 | 480×272 |
| LM050QC1T01 | SHARP | 5.0 | 320×240 |
| LMS500HF06 | Samsung | 5.0 | 480×272 |
| LQ050A5BS01 | SHARP | 5.0 | 320×234 |
| TM050LDZ00 | Tianma | 5.0 | 240×400 |
