| Nomor Bagian | AM-800480AZTMQW-50H |
| Merek | AMPIRE |
| Ukuran | 5.0 |
| Aplikasi | Industrial |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 600:1 |
| Warna | 16.7M |
| Lampu latar | 3S6P |
| Antarmuka | |
| merek panel | AMPIRE |
| ukuran panel | 5.0" |
| resolusi | 800(RGB)×480, WVGA, 188PPI |
| area tampilan | 108(W)×64.8(H) mm |
| ukuran garis besar | 119.7(W)×78(H) ×6.1(D) mm |
| kecerahan | 1000 cd/m² (Typ.) |
| sudut pandang | 75/75/70/60 (Typ.)(CR≥10) |
| tampilan terbaik di | - |
| menampilkan warna | 16.7M 47% NTSC |
| frekuensi | 60Hz |
| berat | - |
| model panel | AM-800480AZTMQW-50H |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | Antiglare |
| rasio kontras | 600:1 (Typ.) (TM) |
| mode tampilan | TN, Normally White, Transmissive |
| waktu merespon | 2/6 (Typ.)(Tr/Td) |
| jenis lampu | 3S6P WLED , 50K hours , Without Driver |
| layar sentuh | Without |
| aplikasi | Industrial |
