| Nomor Bagian | AM-800480AZTMQW-05H |
| Merek | AMPIRE |
| Ukuran | 5.0 |
| Aplikasi | Industrial |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 600:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | |
| merek | AMPIRE |
| model | AM-800480AZTMQW-05H |
| ukuran diagonal | 5.0 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 800(RGB)×480 [WVGA] 188PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 108(H)×64.8(V) mm |
| garis besar redup. | 118.5(H)×77.1(V) ×7.41(D) mm |
| daerah bezel | 110.6(H)×67.4(V) mm |
| perlakuan | - |
| pencahayaan | 500 cd/m² (Typ.) |
| rasio kontras | 600:1 (Typ.) (TM) |
| arah pandangan | - |
| waktu merespon | 2/6 (Typ.)(Tr/Td) |
| sudut pandang | 75/75/70/60 (Typ.)(CR≥10) |
| Modus operasi | TN, Normally White, Transmissive |
| warna pendukung | 262K 47% NTSC |
| sumber cahaya | WLED [3S7P] , 30K hours , With LED Driver |
| berat | - |
| dirancang untuk | Industrial |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
