| Nomor Bagian | AM-640480GJTNQW-TA2H |
| Merek | AMPIRE |
| Ukuran | 5.7 |
| Aplikasi | Industrial |
| Resolusi | 640×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 250:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | AMPIRE |
| model panel | AM-640480GJTNQW-TA2H |
| ukuran panel | 5.7" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 640(RGB)×480, VGA, 141PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 115.2(W)×86.4(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 127(W)×98.43(H) ×10.88(D) mm |
| permukaan | - |
| kecerahan | 425 cd/m² (Typ.) |
| rasio kontras | 250:1 (Typ.) (TM) |
| sudut pandang | 70/70/50/50 (Typ.)(CR≥10) |
| mode tampilan | TN, Normally White, Transmissive |
| tampilan terbaik di | - |
| waktu merespon | 50 (Typ.)(Tr+Td) |
| menampilkan warna | 262K 50% NTSC |
| jenis lampu | WLED , 20K hours , With LED Driver |
| frekuensi | 60Hz |
| layar sentuh | PCAP |
| berat panel | - |
| aplikasi | Industrial |
| antarmuka sinyal | LVDS (1 ch, 8-bit) , 20 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
