| Nomor Bagian | AM-480272METMQW-00H |
| Merek | AMPIRE |
| Ukuran | 4.3 |
| Aplikasi | Industrial |
| Resolusi | 480×272 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 500:1 |
| Warna | 16.7M |
| Lampu latar | 6S2P |
| Antarmuka | Parallel |
| pabrikan | AMPIRE |
| nama model | AM-480272METMQW-00H |
| ukuran layar | 4.3 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 480(RGB)×272 (WQVGA) 128PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 95.04 × 53.856 (H×V) |
| garis besar (mm) | 105.5 × 67.2 (H×V×D) |
| area bezel (mm) | 99.0 × 56.86 (H×V) |
| perlakuan | Antiglare, Hard coating (3H) |
| pencahayaan | 500 cd/m² (Typ.) |
| rasio kontras | 500 : 1 (Typ.) (TM) |
| sudut pandang | 70/70/50/70 (Typ.)(CR≥10) |
| tanggapan | 8/17 (Typ.)(Tr/Td) ms |
| pemandangan bagus di | 12 o'clock |
| mode kerja | TN, Normally White, Transmissive |
| kedalaman warna | 16.7M |
| lampu latar | 6S2P WLED , 25K hours , No Driver |
| massa | - |
| digunakan untuk | Industrial |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| jenis sinyal | Parallel RGB (1 ch, 8-bit) , FPC 40 pins |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
