| Nomor Bagian | AM-320240N1TMQW-TW0H-A(R) |
| Merek | AMPIRE |
| Ukuran | 5.7 |
| Aplikasi | Industrial |
| Resolusi | 320×240 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 350:1 |
| Warna | 65K/262K |
| Lampu latar | 3S7P |
| Antarmuka | |
| pabrikan | AMPIRE |
| nama model | AM-320240N1TMQW-TW0H-A(R) |
| ukuran layar | 5.7 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 320(RGB)×240 (QVGA) 70PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 115.2 × 86.4 (H×V) |
| garis besar (mm) | 167 × 109 × 14.8 (H×V×D) |
| area bezel (mm) | 118.2 × 89.4 (H×V) |
| perlakuan | - |
| pencahayaan | 400 cd/m² (Typ.) |
| rasio kontras | 350 : 1 (Min.) (TM) |
| sudut pandang | 70/70/50/70 (Typ.)(CR≥10) |
| tanggapan | 15/35 (Typ.)(Tr/Td) ms |
| pemandangan bagus di | 6 o'clock |
| mode kerja | TN, Normally White, Transmissive |
| kedalaman warna | 65K/262K 61% NTSC |
| lampu latar | 3S7P WLED , No Driver |
| massa | TBD |
| digunakan untuk | Industrial |
| tingkat penyegaran | 60Hz |
| layar sentuh | 4-wire Resistive Touch |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
