| Nomor Bagian | AM-320240LATNQW-00H-F |
| Merek | AMPIRE |
| Ukuran | 3.5 |
| Aplikasi | HHP |
| Resolusi | 320×240 |
| Komposisi | LCM |
| Kecerahan | 500 |
| CR | 300:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | TTL |
| merek panel | AMPIRE |
| model panel | AM-320240LATNQW-00H-F |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 3.5 inch |
| resolusi | 320(RGB)×240 , QVGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 70.08×52.56 mm |
| garis besar | 77.8×64.5×4.7 mm |
| permukaan | Antiglare |
| kecerahan | 500 cd/m² (Typ.) |
| rasio kontras | 300:1 (Typ.) |
| menampilkan warna | 262K (6-bit) |
| waktu merespon | 50 (Typ.)(Tr+Td) |
| sudut pandang | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 3S2PWLEDWithout Driver |
| antarmuka sinyal | Parallel RGB (1 ch, 6-bit), 40 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | HHP |
