| Nomor Bagian | AM-19201200B1TZQW-00-B |
| Merek | AMPIRE |
| Ukuran | 10.1 |
| Aplikasi | Industrial Outdoor H |
| Resolusi | 1920×1200 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | AMPIRE |
| ukuran diagonal | 10.1 inch |
| format piksel | 1920(RGB)×1200 [WUXGA] 224PPI |
| daerah aktif | 216.806(H)×135.504(V) mm |
| daerah bezel | - |
| pencahayaan | 1000 cd/m² (Typ.) |
| arah pandangan | Symmetry |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| warna pendukung | 16.7M 53% NTSC |
| berat | - |
| kecepatan bingkai | 60Hz |
| tipe antarmuka | LVDS (2 ch, 8-bit) , 40 pins Connector |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: -20 ~ 65 °C ; Storage Temperature: -30 ~ 80 °C |
| model | AM-19201200B1TZQW-00-B |
| jenis | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar redup. | 243.45(H)×155.2(V) ×9.61(D) mm |
| perlakuan | Antiglare |
| rasio kontras | 800:1 (Typ.) (TM) |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| Modus operasi | Normally Black, Transmissive |
| sumber cahaya | WLED , 50K hours , With LED Driver |
| dirancang untuk | Industrial Outdoor High Brightness |
| panel sentuh | Without |
