| Nomor Bagian | AM-1280800W2TZQW-00H |
| Merek | AMPIRE |
| Ukuran | 10.1 |
| Aplikasi | Industrial |
| Resolusi | 1280×800 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | 7S4P |
| Antarmuka | LVDS |
| pabrikan | AMPIRE |
| ukuran layar | 10.1 inch |
| nomor piksel | 1280(RGB)×800 (WXGA) 149PPI |
| area aktif (mm) | 216.96 × 135.6 (H×V) |
| area bezel (mm) | - |
| pencahayaan | 1000 cd/m² (Typ.) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| pemandangan bagus di | Symmetry |
| kedalaman warna | 16.7M 44% NTSC |
| massa | 160g (Max.) |
| tingkat penyegaran | 60Hz |
| jenis sinyal | LVDS (1 ch, 8-bit) , 40 pins Connector |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| nama model | AM-1280800W2TZQW-00H |
| tipe layar | LCM , a-Si TFT-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | 231 × 154.4 × 7.9 (H×V×D) |
| perlakuan | Glare (Haze 0%), Hard coating (3H) |
| rasio kontras | 800 : 1 (Typ.) (TM) |
| tanggapan | 25 (Typ.)(Tr+Td) ms |
| mode kerja | ADS, Normally Black, Transmissive |
| lampu latar | 7S4P WLED , 50K hours , No Driver |
| digunakan untuk | Industrial |
| layar sentuh | Without |
