| Nomor Bagian | AM-1280800P4TZQW-T11H |
| Merek | AMPIRE |
| Ukuran | 7.0 |
| Aplikasi | Industrial |
| Resolusi | 1280×800 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | 6S4P |
| Antarmuka | |
| merek panel | AMPIRE |
| ukuran panel | 7.0" |
| resolusi | 1280(RGB)×800, WXGA, 217PPI |
| area tampilan | 149.76(W)×93.6(H) mm |
| ukuran garis besar | 162.3(W)×107.9(H) ×11.8(D) mm |
| kecerahan | 850 cd/m² (Typ.) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 16.7M 50% NTSC |
| frekuensi | 60Hz |
| berat | - |
| model panel | AM-1280800P4TZQW-T11H |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | 152.76(W)×96.6(H) mm |
| permukaan | - |
| rasio kontras | 800:1 (Typ.) (TM) |
| mode tampilan | SFT, Normally Black, Transmissive |
| waktu merespon | 35 (Typ.)(Tr+Td) |
| jenis lampu | 6S4P WLED , 50K hours , With LED Driver |
| layar sentuh | PCAP |
| aplikasi | Industrial |
