| Nomor Bagian | AM-1280800P4TZQW-T01H |
| Merek | AMPIRE |
| Ukuran | 7.0 |
| Aplikasi | Industrial Outdoor H |
| Resolusi | 1280×800 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | |
| merek | AMPIRE |
| model | AM-1280800P4TZQW-T01H |
| ukuran diagonal | 7.0 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1280(RGB)×800 [WXGA] 217PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 149.76(H)×93.6(V) mm |
| garis besar redup. | 162.3(H)×107.9(V) ×11.76(D) mm |
| daerah bezel | 152.76(H)×96.6(V) mm |
| perlakuan | - |
| pencahayaan | 1275 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 35 (Typ.)(Tr+Td) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| Modus operasi | SFT, Normally Black, Transmissive |
| warna pendukung | 16.7M 50% NTSC |
| sumber cahaya | WLED [5S4P] , 50K hours , With LED Driver |
| berat | - |
| dirancang untuk | Industrial Outdoor High Brightness |
| kecepatan bingkai | 60Hz |
| panel sentuh | PCAP |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
