| Nomor Bagian | AM-1024768V1TZQW-A0H |
| Merek | AMPIRE |
| Ukuran | 8.4 |
| Aplikasi | Industrial |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | AMPIRE |
| model | AM-1024768V1TZQW-A0H |
| ukuran diagonal | 8.4 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1024(RGB)×768 [XGA] 152PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 170.8(H)×128.1(V) mm |
| garis besar redup. | 203(H)×145.5(V) ×8(D) mm |
| daerah bezel | 174.15(H)×131.2(V) mm |
| perlakuan | - |
| pencahayaan | 1000 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 30 (Typ.)(Tr+Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| Modus operasi | IPS, Normally Black, Transmissive |
| warna pendukung | 16.7M |
| sumber cahaya | WLED [6S6P] , 50K hours , With LED Driver |
| berat | - |
| dirancang untuk | Industrial |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| tipe antarmuka | LVDS (1 ch, 8-bit) , 20 pins Connector |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 85 °C |
