| Nomor Bagian | AM-1024768TTMQW-T00H |
| Merek | AMPIRE |
| Ukuran | 10.4 |
| Aplikasi | Industrial |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 900:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | AMPIRE |
| model | AM-1024768TTMQW-T00H |
| ukuran diagonal | 10.4 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1024(RGB)×768 [XGA] 123PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 211.2(H)×158.4(V) mm |
| garis besar redup. | 236(H)×176.9(V) ×7.9(D) mm |
| daerah bezel | 214.8(H)×162.0(V) mm |
| perlakuan | Antiglare |
| pencahayaan | 280 cd/m² (Typ.) |
| rasio kontras | 900:1 (Typ.) (TM) |
| arah pandangan | 6 o'clock |
| waktu merespon | 16 (Typ.)(Tr+Td) |
| sudut pandang | 75/75/75/75 (Typ.)(CR≥10) |
| Modus operasi | TN, Normally White, Transmissive |
| warna pendukung | 262K/16.7M |
| sumber cahaya | WLED [4 strings] , 30K hours , With LED Driver |
| berat | 290g (Max.) |
| dirancang untuk | Industrial |
| kecepatan bingkai | 60Hz |
| panel sentuh | 4-wire Resistive Touch |
| tipe antarmuka | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
