| Nomor Bagian | AM-1024768R2TNQW-T00H |
| Merek | AMPIRE |
| Ukuran | 12.1 |
| Aplikasi | Industrial |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K/16.7M |
| Lampu latar | 10S5P |
| Antarmuka | LVDS |
| merek panel | AMPIRE |
| ukuran panel | 12.1" |
| resolusi | 1024(RGB)×768, XGA, 105PPI |
| area tampilan | 245.76(W)×184.32(H) mm |
| ukuran garis besar | 279(W)×209(H) ×11.2(D) mm |
| kecerahan | 850 cd/m² (Typ.) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| tampilan terbaik di | - |
| menampilkan warna | 262K/16.7M |
| frekuensi | 60Hz |
| berat panel | - |
| antarmuka sinyal | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| model panel | AM-1024768R2TNQW-T00H |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | - |
| rasio kontras | 800:1 (Typ.) (TM) |
| mode tampilan | TN, Normally White, Transmissive |
| waktu merespon | 16 (Typ.)(Tr+Td) |
| jenis lampu | 10S5P WLED , 50K hours , Without Driver |
| layar sentuh | PCAP |
| aplikasi | Industrial |
