| Nomor Bagian | AM-1024768FCTMQW-T00H |
| Merek | AMPIRE |
| Ukuran | 10.4 |
| Aplikasi | Industrial |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 262K/16.2M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | AMPIRE |
| model | AM-1024768FCTMQW-T00H |
| ukuran diagonal | 10.4 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1024(RGB)×768 [XGA] 123PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 210.4(H)×157.8(V) mm |
| garis besar redup. | 238.6(H)×175.8(V) mm |
| pencahayaan | 280 cd/m² (Typ.) |
| rasio kontras | 1200:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 14/11 (Typ.)(Tr/Td) |
| sudut pandang | 88/88/88/88 (Typ.)(CR≥10) |
| Modus operasi | Normally Black, Transmissive |
| warna pendukung | 262K/16.2M 57% NTSC |
| sumber cahaya | WLED , 30K hours , With LED Driver |
| berat | - |
| dirancang untuk | Industrial |
| kecepatan bingkai | 60Hz |
| panel sentuh | PCAP |
| tipe antarmuka | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
