| Nomor Bagian | AM-1024600K7TMQW-T53H |
| Merek | AMPIRE |
| Ukuran | 7.0 |
| Aplikasi | Industrial |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 700:1 |
| Warna | 262K/16.7M |
| Lampu latar | 5S3P |
| Antarmuka | LVDS |
| merek panel | AMPIRE |
| ukuran panel | 7.0" |
| resolusi | 1024(RGB)×600, WSVGA, 169PPI |
| area tampilan | 153.6(W)×90(H) mm |
| ukuran garis besar | 165.5(W)×104.44(H) ×11.93(D) mm |
| kecerahan | 425 cd/m² (Typ.) |
| sudut pandang | 75/75/70/75 (Typ.)(CR≥10) |
| tampilan terbaik di | 6 o'clock |
| menampilkan warna | 262K/16.7M |
| frekuensi | 60Hz |
| berat panel | TBD |
| antarmuka sinyal | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| model panel | AM-1024600K7TMQW-T53H |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | - |
| rasio kontras | 700:1 (Typ.) (TM) |
| mode tampilan | TN, Normally White, Transmissive |
| waktu merespon | 20/20 (Typ.)(Tr/Td) |
| jenis lampu | 5S3P WLED , 50K hours , With LED Driver |
| layar sentuh | PCAP |
| aplikasi | Industrial |
