| Nomor Bagian | AA104VD04 |
| Merek | Mitsubishi |
| Ukuran | 10.4 |
| Aplikasi | Industrial |
| Resolusi | 640×480 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 600:1 |
| Warna | 262K |
| Lampu latar | - |
| Antarmuka | CMOS |
| merek panel | Mitsubishi |
| ukuran panel | 10.4" |
| resolusi | 640(RGB)×480, VGA, 76PPI |
| area tampilan | 211.2(W)×158.4(H) mm |
| kecerahan | - |
| sudut pandang | 70/70/65/65 (Typ.)(CR≥10) |
| tampilan terbaik di | 6 o'clock |
| menampilkan warna | 262K 40% NTSC |
| frekuensi | 60Hz |
| berat panel | 600g (Typ.) |
| antarmuka sinyal | CMOS (1 ch, 6-bit) , 31 pins Connector |
| tegangan masukan | 3.3V (Typ.)(VCC) |
| lingkungan | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -20 ~ 80 °C |
| model panel | AA104VD04 |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| rasio kontras | 600:1 (Typ.) (TM) |
| mode tampilan | TN, Normally White, Transmissive |
| waktu merespon | 4/12 (Typ.)(Tr/Td) |
| jenis lampu | |
| layar sentuh | Without |
| aplikasi | Industrial |
