| Nomor Bagian | A050EAT01.0 |
| Merek | AUO |
| Ukuran | 5.0 |
| Aplikasi | Industrial |
| Resolusi | 1280×720 |
| Komposisi | a-Si TFT-LCD, Assemb |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | MIPI |
| merek | AUO |
| model | A050EAT01.0 |
| ukuran diagonal | 5.0 inch |
| jenis | a-Si TFT-LCD, Assembly |
| format piksel | 1280×720(RGB) [WXGA] 294PPI |
| konfigurasi | RGB Horizontal Stripe |
| daerah aktif | 110.4(H)×62.1(V) mm |
| garis besar redup. | 136.38(H)×91.71(V) ×4.86(D) mm |
| pencahayaan | 800 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 20/15 (Typ.)(Tr/Td) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| Modus operasi | - |
| warna pendukung | 16.7M 66% NTSC |
| sumber cahaya | WLED [7S3P] , W/O Driver |
| berat | 63g (Typ.) |
| dirancang untuk | Industrial |
| kecepatan bingkai | 60Hz |
| panel sentuh | PCAP |
| tipe antarmuka | MIPI (4 data lanes) , 42 pins Connector |
| Sumber Daya listrik | 1.8/3.3V (Typ.)(VDDI/VCI) |
| lingkungan | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AA050ME01--T1 | Mitsubishi | 5.0 | 800×480 |
| AT050TN23 V.1 | Innolux | 5.0 | 640×480 |
| C050FTN01.0 | AUO | 5.0 | 480×234 |
| CLAN050LH21 1XB | CPT | 5.0 | 540×960 |
| LMS500HF05 | Samsung | 5.0 | 480×272 |
| LQ050T3GG01 | SHARP | 5.0 | 400×234 |
| PA050DT2 | E Ink | 5.0 | 320×234 |
| TFD50W52MS3 | TOSHIBA | 5.0 | |
| TFD50W72MS | TOSHIBA | 5.0 | |
| TM050LDZ00 | Tianma | 5.0 | 240×400 |
